Specification:

Material	SUS304,316L,321,Incoloy800,840,600
Diameter	3mm~50mm
Max operating temp	870ºC(1600F)
voltage	Voltage:12V-480V or as customer’s demand
Heat intensity	Not exceeding 30Wcm2 (advisable)
Insulation Material	High-purity Mgo
Reisistance wire element	Ni-Cr or FeCr
Lead Connection Option	Crimped or Swaged leads
Lead and type of connection leads	10" Fiberglass Standard(Wire options:silicone/PFA/high temperature fiberglass/SS braided).
Cold areas	Depends on length and diameter 5-25mm
Internal thermocouple	type J,K or E
Thermocouple Location	Disc End, Sheath, Center of Heater;

Application:

Cartridge heaters are found useful in many applications,such as:

Seal bars

Injection molding manifolds

Mass spectrometry

Rubber molding

Food production

Immersion tank heating

HVAC compressors

Fuel cells

Semiconductors

Medical devices

Sensor measurement devices

Extrusion

Die casting

Hot melt adhesives

Heat staking / hole punch

Plastic welding

Fluid heating
